    6x4 10M3 12M3 Used Concrete Mixer Truck , Howo Ready Mix Concrete Lorry

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : ZZ1257N3841W
    Certification : CCC, ISO, CE
    Price : $14000/unit-$18000/unit
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 30units per month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    6x4 10M3 12M3 Used Concrete Mixer Truck , Howo Ready Mix Concrete Lorry

    Howo 6x4 10M3 12M3 Concrete Mixer Truck Ready Mix Concrete Truck


    Features of Used Howo Truck Mixer:


    Sinotruk howo used concrete mixer truck 10m3 is a vehicle specially used to transport concrete for construction.

    All the concrete mixer trucks are equipped with a mixing drum which keeps mixing the concrete during transportation

    to prevent solidification. Users should clean the interior of the mixing drum after using it, because sclerous concrete

    makes the volume of mixing drum smaller and smaller. The concrete mixer truck is fitted with a diesel 4-stroke direct

    injection engine which produces little greenhouse gases and minimal black smoke emissions.

    PRODUCT SPECIFICATIONS

    Chassis modelZZ1257N3841W (Overall dimension: 8560x2496x3800mm)
    EngineWD615.47, 371hp, Euro II, In-line, six cylinders, two valves, supercharging inter-cooling, rear supercharger Displacement is 9.726L. Diesel fuel type, Max. Torque is 1350/1300-1600Nm/rpm.
    CabinHW76, one sleeper, two seats with air-conditioner, safety belts with double locking mechanism, new face, exterior sun visor, equipped with high position metal bumper.
    Clutch∮430 diaphragm spring clutch, hydraulic control air power assisted.
    TransmissionHW19710, 10 F and 2 R, manual type. Max.torque: 1390N.m
    Drive AxleHC16, double reduction (central reduction+hub reduction), speed ratio:standard 5.73, optional 4.8.
    Front AxleHF9, 9ton, drum brake
    ChassisFrame: U-profile parallel ladder frame with section of 300x80x8mm and reinforced sub-frame, all cold riveted cross member, Equipped with HW50 PTO
    Front suspension: semi-elliptic leaf springs, hydraulic telescopic double-action shock absorber and stabilizer
    Rear suspension: semi-elliptic leaf springs and bogie springs, spare wheel
    Fuel tank: 300 L capacity, with locking fuel cap
    SteeringZF8118, hydraulic steering with power assistance, LHD
    Brake systemService brake: dual circuit pneumatic brake, Parking brake:energy storage spring cutoff brake.Optional ABS and automatic slack adjust.
    Tyre12.00R20 Radial plus one spare tyre (11 units)
    Mixing TankEffective tank volume is 10m3, speed of mixing barrel is 0-16r/min, mixing obliquity is 10°,capacity of water tank is 400L, Max. Dimension of hopper is 980mm
    Other SpecificationWith Italian brand Bonfiglioli reduction gears, America brand Eton oil pump and motor
