    Used Howo 14M3 16M3 18M3 Mobile Concrete Mixer Truck

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : ZZ1257N3841W
    Certification : CCC, ISO, CE
    Price : $14000/unit-$18000/unit
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 30units per month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    Used Howo 14M3 16M3 18M3 Mobile Concrete Mixer Truck

    Used Howo 12,14,16,18 Concrete Transit Mobile Concrete Mixer Truck


    Features of Used Howo Concrete Mixer Truck:


    Stepless speed change

    Manual transmission and heavy truck 10 transmission change the transmission ratio and expand the variation

    range of driving wheel torque and speed to adapt to frequently changing driving conditions; When the rotation

    direction of the engine remains unchanged, the vehicle can travel backwards; Use neutral gear to interrupt power

    transmission, so that the engine can start, change speed, and facilitate transmission shift or power output.


    Mixing drum

    High quality steel plate is stable and wear-resistant.

    The mixing tank body is made of alloy steel manganese steel (Q345), with higher strength. The mixing blade is

    double helix logarithmic thickened blade, which is more wear-resistant. The internal blade is made of fine grain

    alloy steel (520jj), with unique angle design, more uniform mixing and lower discharge residue rate. Thickened

    high-quality wear-resistant alloy steel head, more stable and dense.


    SPECIFICATIONS OF HOWO MIXING TRUCK

    BrandSinotruk Howo
    CabinDriving type 8X4, LHD
    HW76 single bed
    Vehicle Main DimensionsOverall dimensions (L x W x H)mm10245x2496x3450
    Wheel base (mm)3600+1350
    Wheel track (front/rear) (mm)2022/2022
    Approach/Departure angle(°)16/24
    Max. driving speed(km/h)90
    EngineType4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
    ModelWD615.47
    Horse Power(HP)371
    Emission standardEuro II
    Gearbox10 forwards & 2 reverse
    SteeringLeft hand drive
    Tire12R22.5 tubeless tires with one spare
    Mixer DrumMixer Capacity16 cubic meters
    Drum thickness6mm
    Blade thickness4mm
    Tanker Material:16MnQ345 Carbon Steel
    Filling Rate(%)59
    Input Speed (m3/min)≥2.8
    Output Speed (m3/min)≥1.2
    Surplus Ratio≤0.5
    Tanker Rotate Speed(rpm)0~17
    Hydraulic PumpItaly Brand: PMP
    Drum Drive SystemHydraulic MotorItaly Brand: PMP
    Speed ReducerGermany Brand: ZF
    RadiatorKAITONG
    Water Tank Volume(L)400
